Wi-Fi

802.11ax/ac/a/n 2 x 2 & 802.11b/g/n 2 x 2, MIMO

up to 300 Mbit/s over a 2.4 GHz Wi-Fi network

 2.4 GHz

Memory

128 Mbytes RAM + 128 Mbytes ROM

*Due to limitations in CPU processing power, memory used by the operating system and pre-installed applications, the actual space available to users may be less than the stated memory capacity. Actual memory space may change due to application updates, user operations, and other related factors.

Network Port

three 10/100/1000 Mbps WAN/LAN ports, auto-adaptation

Interface

Power port, Network port, WPS/Reset button

LED Indicator

one LED Indicator

Power Supply

Power: < 12 W

AC / DC Power Supply: 12V DC, 1 A

Software Functions

HUAWEI AI Life APP

802.11kv protocol,IPv4/IPv6,Wi-Fi timer,Guest Wi-Fi,Device speed limiting,MAC address filter,Parental control,VPN pass through, DMZ/virtual server,PPPoE/DHCP/Static IP address/Bridge WAN connection methods

Security

WPA3 ,Wi-Fi access control, Guest Wi-Fi, SSID hidden,  Firewall,  DMZ, Parental Control

Environment

Operating temperature: 0 °C ~ 40 °C,

storage temperature: -40 °C ~ +70 °C

Operating humidity: 5% to 95% RH (non-condensing)

Storage humidity: 5% to 95%, non-condensing

Key

WPS/Reset, 2 in 1

Packing List

Power adapter: 1

Network cable: 1

Quick Start Guide and Safety Information: 1

Warranty Card: 1
