General Parameters
-
Ton:1.5 Ton
-
Fixed or inverter:DC Inverter
-
Cooling Capacity(BTU):19000
-
Heating Capacity(BTU):19500
-
Air Circulation(m³/h):850
-
Power Input(W)-Cooling:410 ~ 2200
-
Power Input(W)-Heating:420 ~ 2250
-
Running Current(A)-Cooling:2.3 ~10.2
-
Running Current(A)-Heating:2.4 ~10.3
-
Power Supply (Ph/V/Hz):1/220/50
-
Capacity wise:1.5-Ton
-
Category wise:DC Inverter
Appearance
-
Color:White
-
Type:Wall Mount
-
Display:Hidden LED
Main Parts
-
Refrigerant:R32
-
Refrigerant pipe:Liq Side: 6mm, Gas side: 12mm
Net Dimension&Weight
-
Indoor Dimension(mm) W/D/H:900/310/215
-
Outdoor Dimension(mm) W/D/H:820/300/610
-
Indoor Weight(kg):12.5
-
Outdoor Weight(kg):34
Noise
-
Indoor Noise[dB(A)] (H/M/L):47/43/39
-
Outdoor Noise[dB(A)]:55
Mobile App
-
Haier Smart Air:https://uhome.haieriot.net/download/airkit/
Warranty
-
Warranty:10 Years Compressor, 4 Years PCB, 1 Year Parts
